Description
Product Features:
- Programmable, Without the need of Powering on the Driver
- Isolated Dimming Controls:1-5V, 1-10V, 10V PWM, Multiple Timers
- Built-in Surge Protection:4kV DM, 6kV CM
- Output Lumen Compensation
- Class 2 Models Available
- SELV Output Models Available
- UL Class P
- Type HL, for Use in a Class I, Division 2 Hazardous (Classified) Location
- IP66 Rated with UL Dry, Damp
- 5 years warranty
Detail models with packing information:
| Model | Adjustable Output Current Range |
Full-Power Current Range(1) |
Default Output Current |
Input voltage | Max. Output power | Output vol. | Effi. | QTY per carton (pcs) |
carton size (cm) |
GW per carton (kg) |
| EUM-030S050DG | 30-500mA | 300-500mA | 350mA | 90~305 Vac/127~300 Vdc | 30w | 30~100 Vdc | 88.00% | 40 | 54*36*31 | 22 |
| EUM-030S105DG | 55-1050mA | 550-1050mA | 700mA | 90~305 Vac/127~300 Vdc | 30w | 17~54 Vdc | 87.00% | |||
| EUM-030S050DT | 30-500mA | 300-500mA | 350mA | 90~305 Vac/127~300 Vdc | 30w | 30~100 Vdc | 88.00% | 40 | 54*36*31 | 22 |
| EUM-030S105DT | 55-1050mA | 550-1050mA | 700mA | 90~305 Vac/127~300 Vdc | 30w | 17~54 Vdc | 87.00% | |||
| EUM-030S050DB | 30-500mA | 300-500mA | 350mA | 90~305 Vac/127~300 Vdc | 30w | 30~100 Vdc | 88.00% | 40 | 54*36*31 | 22 |
| EUM-030S105DB | 55-1050mA | 550-1050mA | 700mA | 90~305 Vac/127~300 Vdc | 30w | 17~54 Vdc | 87.00% | |||
| EUM-030S050DF | 30-500mA | 300-500mA | 350mA | 90~305 Vac/127~300 Vdc | 30w | 30~100 Vdc | 88.00% | 40 | 54*36*31 | 22 |
| EUM-030S105DF | 55-1050mA | 550-1050mA | 700mA | 90~305 Vac/127~300 Vdc | 30w | 17~54 Vdc | 87.00% |
Notes: (1) Output current range with constant power at 30W
(2) Certified input voltage range: UL, FCC 100-277Vac; otherwise 100-240Vac.
(3) Measured at 100% load and 220Vac input (see below “General Specifications” for details).
(4) SELV output.
(5) Class 2 & SELV output.
(6) DG are UL Recognized, ENEC and CCC, etc. models; DT are UL Class P models;D B are BIS models;
DF are UL Class P models with flying leads. See drawings for cable information.
