Description
Features:
- Compact Metal Housing
- Input Surge Protection:4kV DM, 6kV CM
- Built-in Protection for Unstable Input Lines:
Input Under Voltage Protection
Input Over Voltage Protection - Low Total Harmonic Distortion (THD), 10% Max up to 240 Vac
- Suitable for Independent Use and Class I Luminaires
- SELV Output
- 5 Year Warranty
Detail models:
| Model | Output Current (A) |
Input voltage (Vac) |
Output Voltage (V) |
Output power (W) |
Effi. | QTY per carton (pcs) |
carton size (cm) |
GW per carton (kg) |
| EUC-035S070SVM0004 | 500mA | 90 ~ 305Vac | 32 ~ 64Vdc | 35W | 87.00% | 54 | 54*36*31 | 23 |
| EUC-035S070SVM | 700mA | 90 ~ 305Vac | 25 ~ 47Vdc | 35W | 86.00% | 54 | 54*36*31 | 23 |
| EUC-035S105SVM0004 | 860mA | 90 ~ 305Vac | 20 ~ 41Vdc | 35W | 86.00% | 54 | 54*36*31 | 23 |
| EUC-035S105SVM | 1050mA | 90 ~ 305Vac | 18 ~ 33Vdc | 35W | 86.00% | 54 | 54*36*31 | 23 |
Notes: (1) Certified input voltage range: 120-240Vac or 127-250Vdc.
(2) Measured at 100% load and 220 Vac input.
(3) SELV output.
