Description
Features:
- Programmable, Without the need of Powering on the Driver
- New Global Cable Design to Reduce SKUs (with UL)
- Isolated Dimming Controls:1-5V, 1-10V, PWM, Multiple Timers
- High Level of Built-in Surge Protection:6kV DM, 10kV CM
- Simplified Design for Easier Hi-Pot Testing
- Output Lumen Compensation
- SELV Output Models Available
- IP66 and IP67 and UL Dry, Damp, Wet Location
- TYPE HL, for use in a Class I, Division 2 Hazardous
- EUM-075SxxxDG Models: Global Cable to Reduce Inventory SKUs
- EUM-075SxxxDB Models: BIS Certified
- 5 Year Warranty
Detail models with packing information:
| Model | Adjustable Output Current Range | Full-Power Current Range(1) | Default Output Current | Input voltage | Output power | Output vol. | Effi. | QTY per carton (pcs) | carton size (cm) | GW per carton (kg) |
| EUM-075S053DG | 30-530mA | 300-530mA | 530 mA | 90~305 Vac/127~431 Vdc | 75w | 70~250 Vdc | 92.00% | 25 | 49*30*31 | 19 |
| EUM-075S105DG | 70-1050mA | 700-1050mA | 700mA | 90~305 Vac/127~431 Vdc | 75w | 36~107Vdc | 91.00% | |||
| EUM-075S150DG | 105-1500mA | 1050-1500mA | 1050mA | 90~305 Vac/127~431 Vdc | 75w | 25~72Vdc | 90.50% | |||
| EUM-075S210DG | 140-2100mA | 1400-2100mA | 2100mA | 90~305 Vac/127~431 Vdc | 75w | 18~54Vdc | 90.00% | |||
| EUM-075S053DT | 30-530mA | 300-530mA | 530 mA | 90~305 Vac/127~431 Vdc | 75w | 70~250 Vdc | 92.00% | 25 | 49*30*31 | 19 |
| EUM-075S105DT | 70-1050mA | 700-1050mA | 700mA | 90~305 Vac/127~431 Vdc | 75w | 36~107Vdc | 91.00% | |||
| EUM-075S150DT | 105-1500mA | 1050-1500mA | 1050mA | 90~305 Vac/127~431 Vdc | 75w | 25~72Vdc | 90.50% | |||
| EUM-075S210DT | 140-2100mA | 1400-2100mA | 2100mA | 90~305 Vac/127~431 Vdc | 75w | 18~54Vdc | 90.00% | |||
| EUM-075S053DB | 30-530mA | 300-530mA | 530 mA | 90~305 Vac/127~431 Vdc | 75w | 70~250 Vdc | 92.00% | 25 | 49*30*31 | 19 |
| EUM-075S105DB | 70-1050mA | 700-1050mA | 700mA | 90~305 Vac/127~431 Vdc | 75w | 36~107Vdc | 91.00% | |||
| EUM-075S150DB | 105-1500mA | 1050-1500mA | 1050mA | 90~305 Vac/127~431 Vdc | 75w | 25~72Vdc | 90.50% | |||
| EUM-075S210DB | 140-2100mA | 1400-2100mA | 2100mA | 90~305 Vac/127~431 Vdc | 75w | 18~54Vdc | 90.00% |
Notes: (1) Output current range with constant power at 75W
(2) Certified input voltage range: UL, FCC 100-277Vac; otherwise 100-240Vac.
(3) Measured at 100% load and 220Vac input (see below “General Specifications” for details).
(4) SELV Output.
(5) Class 2 & SELV output.
(6) DG are UL Recognized, ENEC and CCC, etc. models;DT are UL Class P models;DB are BIS models.
(7) Only available with DG, and only with ENEC, CE, CB and CCC certificates.
