EUM-075SxxxMG series led driver

The EUM-075SxxxMG series is suitable for global use. They consist of global, IP66/IP67 LED drivers that provide Always-On Auxiliary Power and Dim-to-Off functionality for powering low voltage controls. They also offer programmability, driver health monitoring with digital dimming, isolated dimming, design flexibility, a high level of surge protection and a global cable that helps reduce SKUs for world-wide use. They operate from 90-305Vac and provide the full 75W at a wide output current range.  They are ideal for high bay, area and roadway lighting applications.

Category: Tag:

Description

Features:

  • Full-Power at a Wide Output Current Range
  • Isolated Dimming Controls:0-10V, PWM, Multiple Timers
  • Controls-Ready: Always-On Auxiliary Power: 12Vdc, 250mA, 3W (Transient Peak Power up to 10W), Dim-to-Off
  • High Level of Built-in Surge Protection:6kV DM, 10kV CM
  • Inventronics Proprietary Digital Dimming Health Monitoring:UART Based Communication Protocol
  • Global Cable Design to Reduce SKUs (with UL)
  • Optimized, More Compact Form Factor
  • End-of-Life Indicator
  • Output Lumen Compensation
  • Class 2 and SELV Output Models Available
  • IP66 and IP67 and UL Dry, Damp, Wet Location
  • TYPE HL, for use in a Class I, Division 2 Hazardous
  • 5 Year Warranty

Detail models with packing information

Model Adjustable
Output Current
Range		 Full-Power
Current
Range(1)		 Default
Output
Current		 Input voltage Output power Output vol. Effi. QTY per carton
(pcs)		 carton size
(cm)		 GW per carton
(kg)
EUM-075S105MG 70-1050mA 700-1050mA 700mA 90~305Vac/127~431Vdc 75w 36~107Vdc 91.00% 25 49*30*31 19
EUM-075S150MG 105-1500mA  1050-1500mA 1050mA 90~305Vac/127~431Vdc 75w 25~72Vdc 90.50%
EUM-075S210MG 140-2100mA  1400-2100mA 2100mA 90~305Vac/127~431Vdc 75w 18~54Vdc 90.00%
EUM-075S105MT 70-1050mA 700-1050mA 700mA 90~305Vac/127~431Vdc 75w 36~107Vdc 91.00% 25 49*30*31 19
EUM-075S150MT 105-1500mA  1050-1500mA 1050mA 90~305Vac/127~431Vdc 75w 25~72Vdc 90.50%
EUM-075S210MT 140-2100mA  1400-2100mA 2100mA 90~305Vac/127~431Vdc 75w 18~54Vdc 90.00%

Notes: (1) Output current range with constant power at 75W
(2) Certified input voltage range: UL, FCC 100-277Vac; otherwise 100-240Vac.
(3) Measured at 100% load and 220Vac input (see below “General Specifications” for details).
(4) SELV output.
(5) Class 2 & SELV output.
(6) MG are UL Recognized, ENEC and CCC, etc. models; MT are UL Class P models;
