Description
Features:
- High Efficiency (Up to 93.0%)
- Full Power at Wide Output Current Range (Constant Power)
- Adjustable Output Current (AOC) with Potentiometer
- Non-dimming Control
- Input Surge Protection: DM 4kV, CM 6kV
- All-Around Protection: OVP, SCP, OTP
- IP66/IP67
- 5 Year Warranty
Detail models:
| Model | Adjustable Output Current Range | Full-Power Current Range(1) | Default Output Current | Input voltage | Output power | Output vol. | Effi. | QTY per carton (pcs) | carton size (cm) | GW per carton (kg) |
| EUM-150S105SV | 525-1050mA | 700-1050mA | 700mA | 90~305Vac | 150W | 72~214Vdc | 93.00% | 25 | 49*30*31 | 21 |
| EUM-150S150SV | 750-1500mA | 1050-1500mA | 1050mA | 90~305Vac | 150W | 50~143Vdc | 93.50% | 25 | 49*30*31 | 21 |
| EUM-150S151SV | 1050-2100mA | 1400-2100mA | 1400mA | 90~305Vac | 150W | 36~107Vdc | 92.00% | 25 | 49*30*31 | 21 |
| EUM-150S152SV | 2100-4200mA | 2800-4200mA | 3150mA | 90~305Vac | 150W | 18 ~ 54Vdc | 91.50% | 25 | 49*30*31 | 21 |
Notes: (1) Output current range with constant power at 150W.
(2) Certified input voltage range: 100-240Vac.
(3) Measured at 100% load and 220Vac input (see below “General Specifications” for details).
(4) SELV output.
