Description
Features:
- High Efficiency (Up to 94.0%)
- Full Power at Wide Output Current Range (Constant Power)
- Adjustable Output Current (AOC) with Potentiometer
- Non-dimming Control
- Input Surge Protection:DM 4kV, CM 6kV
- All-Around Protection
- OVP, SCP, OTP
- IP66 and IP67 Rated
- 5 Year Warranty
Detail models:
| Model | Adjustable Output Current Range | Full-Power Current Range(1) | Default Output Current | Input voltage | Output power | Output vol. | Effi. | QTY per carton (pcs) | carton size (cm) | GW per carton (kg) |
| EUM-200S105SV | 70-1050mA | 700-1050mA | 700mA | 90~305Vac | 200W | 95~286Vdc | 93.50% | 25 | 49*30*31 | 25 |
| EUM-200S150SV | 105-1500mA | 1050-1500mA | 1050mA | 90~305Vac | 200W | 67~190Vdc | 92.50% | 25 | 49*30*31 | 25 |
| EUM-200S280SV | 180-2800mA | 1800-2800mA | 2100mA | 90~305Vac | 200W | 36~111Vdc | 93.00% | 25 | 49*30*31 | 25 |
| EUM-200S560SV | 350-5600mA | 3500-5600mA | 4200mA | 90~305Vac | 200W | 18 ~ 57Vdc | 92.50% | 25 | 49*30*31 | 25 |
Notes: (1) Output current range with constant power at 200W.
(2) Certified input voltage range: 100-240Vac.
(3) Measured at 100% load and 220Vac input (see below “General Specifications” for details).
(4) SELV output.
