Description
Features:
- Full-Power at a Wide Output Current Range
- Isolated Dimming Controls:0-10V, PWM, Multiple Timers
- Controls-Ready
Always-On Auxiliary Power: 12Vdc, 250mA, 3W (Transient Peak Power up to 10W)
Dim-to-Off - Inventronics Proprietary Digital Dimming Health Monitoring
UART Based Communication Protocol - Global Cable Design to Reduce SKUs (with UL)
- Optimized, More Compact Form Factor
- High Level of Built-in Surge Protection:6kV DM, 10kV CM
- End-of-Life Indicator
- Simplified Design for Easier Hi-Pot Testing
- Output Lumen Compensation
- SELV Output Models Available
- IP66 and IP67 and UL Dry, Damp, Wet Location
- TYPE HL, for use in a Class I, Division 2 Hazardous
- 5 Year Warranty
Detail models:
| Model | Adjustable Output Current Range | Full-Power Current Range(1) | Default Output Current | Input voltage | Output power | Output vol. | Effi. | QTY per carton (pcs) | carton size (cm) | GW per carton (kg) |
| EUM-240S105MG | 70-1050mA | 700-1050mA | 700mA | 90~305Vac | 240W | 115~343Vdc | 94.0% | 20 | 49*30*31 | 23 |
| EUM-240S150MG | 105-1500mA | 1050-1500mA | 1050mA | 90~305Vac | 240W | 80~229Vdc | 93.50% | 20 | 49*30*31 | 23 |
| EUM-240S350MG | 215-3500mA | 2150-3500mA | 2150mA | 90~305Vac | 240W | 35~111Vdc | 93.00% | 20 | 49*30*31 | 23 |
| EUM-240S670MG | 420-6700mA | 4200-6700mA | 4900mA | 90~305Vac | 240W | 18~57Vdc | 92.50% | 20 | 49*30*31 | 23 |
Notes: (1) Output current range with constant power at 240W.
(2) Certified input voltage range: UL, FCC 100-277Vac; otherwise 100-240Vac.
(3) Measured at 100% load and 220Vac input (see below “General Specifications” for details).
(4) MG are UL Recognized, ENEC and CCC, etc. models;
(5) SELV output.
