Description
Features:
- Programmable, Without the need of Powering on the Driver
Full Power at a Wide Output Current Range - New Global Cable Design to Reduce SKUs (with UL)
- Isolated Dimming Controls:1-5V, 1-10V, PWM, Multiple T imers
- Optimized, More Compact Form Factor
- High Level of Built-in Surge Protection:6kV DM, 10kV CM
- Output Lumen Compensation
- SELV Output Models Available
- IP66 and IP67 and UL Dry, Damp, Wet Location
- TYPE HL, for use in a Class I, Division 2 Hazardous
- EUM-240SxxxDG Models: Global Cable to Reduce Inventory SKUs
- EUM-240SxxxDB Models: BIS Certified
- 5 Year Warranty
Detail models:
| Model | Adjustable Output Current Range | Full-Power Current Range(1) | Default Output Current | Input voltage | Output power | Output vol. | Effi. | QTY per carton (pcs) | carton size (cm) | GW per carton (kg) |
| EUM-320S105DG | 70 ~ 1050 | 700-1050mA | 700mA | 90~305Vac | 320w | 153 ~ 457Vdc | 94.50% | 12 | 49*30*31 | 19 |
| EUM-320S150DG | 105 ~ 1500 | 1050-1500mA | 1400mA | 90~305Vac | 320w | 107 ~ 305Vdc | 94.00% | 12 | 49*30*31 | 19 |
| EUM-320S250DG | 175 ~ 2500 | 1750-2500mA | 2100mA | 90~305Vac | 320w | 64 ~ 183Vdc | 94.00% | 12 | 49*30*31 | 19 |
| EUM-320S500DG | 285 ~ 5000 | 2850-5000mA | 4900mA | 90~305Vac | 320w | 32 ~ 112Vdc | 93.50% | 12 | 49*30*31 | 19 |
| EUM-320S760DG | 535 ~ 7600 | 5350-7600mA | 6700mA | 90~305Vac | 320w | 21 ~ 60Vdc | 92.50% | 12 | 49*30*31 | 19 |
Notes: (1) Output current range with constant power at 320W.
(2) Certified input voltage range: UL, FCC 100-277Vac; otherwise 100-240Vac.
(3) Measured at 100% load and 220Vac input (see below “General Specifications” for details).
(4) SELV output.
(5) DG are UL Recognized, ENEC and CCC, etc. models;
