Description
Product features
- Input voltage: 90 ~ 305Vac;
- Isolated constant power design;
- Off-line programmable;
- 12V/0.2A auxiliary output optional (for 320W);
- 0-5V/0-10V/PWM/timer dimming, optional reverse dimming, Dim-to-off, CLO, work log function;
- Surge protection: DM 5KV, CM 10KV;
- All-around protection: output SCP, OVP, OTP;
- Degree of waterproof: IP67;
- Warranty: 5 years.
Application
-
- Suitable for LED roadway lighting, plant lighting, industrial lighting, landscape lighting, etc.
Detail models with packing information:
| Model | Input voltage | Max Output Power (W) | Output Voltage Range (Vdc) | Full Power Output Voltage Range (Vdc) | Full Power Current Adjustable Range (A) | Default Output Current Setting (A) | Typical Efficiency | PF | QTY per carton (pcs) | carton size (cm) | GW per carton (kg) |
| X6-075M041 | 90~305Vac | 75 | 20-41 | 28-41 | 1.83-2.67 | 2.10 | 88% | 0.96 | 10 | 50*31*16 | 6.3 |
| X6-075V041 | 90~305Vac | 75 | 20-41 | 28-41 | 1.83-2.67 | 2.10 | 88% | 0.96 | 10 | 50*31*16 | 6.3 |
| X6-075M062 | 90~305Vac | 75 | 38-62 | 40-62 | 1.21-1.88 | 1.40 | 89% | 0.96 | 10 | 50*31*16 | 6.3 |
| X6-075V062 | 90~305Vac | 75 | 38-62 | 40-62 | 1.21-1.88 | 1.40 | 89% | 0.96 | 10 | 50*31*16 | 6.3 |
| X6-075M108 | 90~305Vac | 75 | 54-108 | 71-108 | 0.7-1.05 | 0.70 | 90% | 0.96 | 10 | 50*31*16 | 6.3 |
| X6-075V108 | 90~305Vac | 75 | 54-108 | 71-108 | 0.7-1.05 | 0.70 | 90% | 0.96 | 10 | 50*31*16 | 6.3 |
Notes
[1]. M means dimmable and offline programmable, The adjustable Iout range: 10%-100% Imax; V means non-dimmable and output current adjusted by built-in potentiometer.
[2]. Output current adjustable range with constant power at max output power;
[3]. All specifications are measured at 25℃ ambient temperature, input voltage 230Vac, and the typical value tested by full load, if no specific note.
